Chevrolet Chevy Express H2500 (2003-2003) underhood fuse block btsi fuse 28 Wiring diagram
This page shows the only wiring diagram for the component.underhood fuse block btsi fuse 28, which is found in the car Chevrolet Chevy Express H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram underhood fuse block btsi fuse 28 (1 of 1)
A/T SHIFT LOCK CONTROL SOLENOID (RIGHT SIDE OF STEERING COLUMN)
BLK WIRE
DK GRN WIRE
HOT IN RUN OR START BTSI/BU FUSE 36
LT GRN WIRE
PARK/ NEUTRAL POSITION SWITCH (ON LEFT SIDE OF TRANSMISSION)
PNK WIRE
STOPLAMP SWITCH (ABOVE BRAKE PEDAL)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK BTSI FUSE 28
WHT WIRE
Go to component -> Shift interlock circuit -> UNDERHOOD FUSE BLOCK BTSI FUSE 28
