Chevrolet Chevy Express H2500 (2003-2003) turn signal/ malfunction switch Wiring diagram
This page shows the only wiring diagram for the component.turn signal/ malfunction switch, which is found in the car Chevrolet Chevy Express H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn signal/ malfunction switch (1 of 1)
+BC
BLK WIRE
BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
COMPOSITE SEALED
COMPOSITE+
DIMMER SWITCH SIGNAL
DK GRN WIRE
FLASH TO PASS SIGNAL
FTP
FUSE LINK B
HDLP HIBM RELAY
HDLP LOBM RELAY
HEAD
HEADLAMP DIMMER SWITCH
HEADLAMP ON SIGNAL
HEADLAMP, PANEL DIMMER SWITCH
HIGH BEAM RELAY CONTROL
HOT AT ALL TIMES
LEFT HIGH BEAM HEADLAMP LEFT HEADLAMP
LEFT LOW BEAM HEADLAMP
LH- HIBM FUSE 44
LH- HIBM FUSE 45
LH- LOBM FUSE 43
LOW BEAM RELAY CONTROL
LT GRN WIRE
OFF
PARK
PNK WIRE
PNK/WHT WIRE
RED WIRE
RH- LOBM FUSE 42
RIGHT HEADLAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
SEALED
TAN WIRE
TAN/WHT WIRE
TURN SIGNAL/ MALFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit -> TURN SIGNAL/ MALFUNCTION SWITCH
