Chevrolet Chevy Express H2500 (2003-2003) sw lock ctrl sw unlock ctrl unlock rly ctrl release rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.sw lock ctrl sw unlock ctrl unlock rly ctrl release rly ctrl, which is found in the car Chevrolet Chevy Express H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sw lock ctrl sw unlock ctrl unlock rly ctrl release rly ctrl (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
BODY FUSE BLOCK (UNDER LEFT FRONT SEAT)
CARGO DOOR JAMB SWITCH
CARGO UNLK FUSE 5
CARGO UNLK RELAY
DK BLU WIRE
DOOR LKS FUSE 15
DOOR LKS RELAY
DOOR LOCK CTRL UNLOCK CTRL
DRIVER DOOR JAMB SWITCH
DRIVER DOOR LOCK SWITCH
DRV LKS FUSE 7
DRV UNLK RELAY
FRONT PASSENGER DOOR JAMB SWITCH
FRONT PASSENGER DOOR LOCK SWITCH REAR CARGO DOOR LOCK SWITCH
GRY WIRE
HOT AT ALL TIMES
LEFT DOOR CONTACT PLATE (LEFT "B" PILLAR)
LEFT REAR DOOR LOCK ACTUATOR
LT BLU WIRE
LT GRN WIRE
PASS UNLK RELAY
PASSENGER VAN
PILLAR)
RIGHT DOOR CONTACT PLATE (RIGHT "B"
RIGHT REAR DOOR LOCK ACTUATOR
SPLICE PACK (TOP OF LEFT "D" PILLAR)
SW LOCK CTRL SW UNLOCK CTRL UNLOCK RLY CTRL RELEASE RLY CTRL
TAN WIRE
TAN/BLK WIRE
WHT WIRE
Go to component -> Power door locks circuit -> SW LOCK CTRL SW UNLOCK CTRL UNLOCK RLY CTRL RELEASE RLY CTRL
