Chevrolet Chevy Express H2500 (2003-2003) passlock signal Wiring diagram
This page shows the only wiring diagram for the component.passlock signal, which is found in the car Chevrolet Chevy Express H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passlock signal (1 of 1)
1836 710 351 PASSLK SENS SERIAL DATA GROUND
39 343 PNK IGN 1 VOLT ACC VOLT WIRE
B+ GROUND SENS RET SERIAL DATA
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
DK SERIAL DATA
ELECTRONIC BRAKE CONTROL MODULE (ON LEFT FRAME RAIL NEAR CENTER OF VEHICLE)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT ON ACC OR RUN
HOT ON RUN OR START
INSTRUMENT PANEL CLUSTER
LT GRN WIRE
LT SERIAL DATA
ORG/WHT WIRE
PASSLOCK SENSOR (INSIDE TOP OF STEERING COLUMN)
PASSLOCK SIGNAL
PNK WIRE
POWERTRAIN CONTROL MODULE (ENGINE COMPT, ON LEFT INNER FENDER)
PPL
RED/WHT WIRE
SECURITY INDICATOR
SENSOR RETURN
SERIAL DATA
SPLICE
TAN WIRE
TBC ACC FUSE 46
TBC FUSE 19
TBC IGN 1 FUSE 24
UNDERHOOD FUSE BLOCK
YEL WIRE
Go to component -> Anti-theft circuit -> PASSLOCK SIGNAL
