Chevrolet Chevy Express H2500 (2003-2003) dk cruise control system Wiring diagram
This page shows the only wiring diagram for the component.dk cruise control system, which is found in the car Chevrolet Chevy Express H2500 (2003-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dk cruise control system (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
BODY FUSE BLOCK (BELOW LEFT FRONT SEAT)
BODY FUSE BLOCK (BELOW LEFT FRONT SEAT) STOP/ CHMSL FUSE 8
BRN WIRE
BRN/WHT WIRE
CHMSL/ STOP LAMP SUPPLY VOLTAGE
DK BLU WIRE
DK BLU/WHT WIRE
DK CRUISE CONTROL SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DK USED
DR TRN MIR FUSE 14
DRIVER'S OUTSIDE REAR VIEW MIRROR (LEFT TURN SIGNAL)
DRL ON/OFF SIG
FR PRK FUSE 22
FRONT TURN SIGNAL LAMP SUPPLY VOLTAGE
GRN WIRE
HAZARD SWITCH
HEAD OFF
HEADLAMP AND PANEL DIMMER SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
LEFT
LEFT TAIL LAMP ASSEMBLY
LEFT TURN SIGNAL IND LOGIC
LICENSE LAMP
LP PKR FUSE 18
LR STOP/ TURN FUSE 4
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN/BLK WIRE
NCA WIRE
NOT USED
PARK
PARK LAMP RELAY
PARK LAMP RLY CTRL HAZARD SW SIG DRL LOW CONTROL
PARK LAMP SW ON SIG
PASS TRN MIR FUSE 19
PASSENGER'S OUTSIDE REAR VIEW MIRROR (RIGHT TURN SIGNAL)
PNK WIRE
PROVISIONAL
RED/WHT WIRE
RIGHT
RIGHT TAIL LAMP ASSEMBLY CENTER HIGH MOUNTED STOP LAMP
RIGHT TURN SIGNAL IND
RR STOP/ TURN FUSE 6
SPLICE PACK
TAIL/ STOP/ TURN SIGNAL LAMP
TRAILER WIRING (BLUNT CUT)
TRLR PRK FUSE 21
TURN SIGNAL SWITCH
TURN SIGNAL/ MULTIFUNCTION SWITCH
TURN SIGNAL/HAZARD FLASHER MODULE (BEHIND LEFT SIDE OF DASH)
UPFTR PRK FUSE 16
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit, except cutaway (1 of 2) -> DK CRUISE CONTROL SYSTEM
