Cruise control circuit, with active handling for Chevrolet Chevy Express H1500 (2003-2012)

BLK WIRE BODY FUSE BLOCK (BELOW LEFT FRONT SEAT) CLASS 2 CLASS 2 (PCM) DATA COMPUTER DATA LINES SYSTEM CRUISE IND DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE GRN WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN, START IGN IGN E FUSE 22 INSTRUMENT PANEL CLUSTER LT BLU WIRE NCA WIRE ON CRUISE CONTROL ON/OFF SWITCH OFF ON OFF ORG/BLK WIRE PCM IGN 1 FUSE 38 PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (IN ENGINE COMPT, ON LEFT INNER FENDER) PPL PPL VSS LOW RED/WHT WIRE RESUME/ ACCEL RESUME/ACCEL SET/ COAST STOP LP FUSE 7 STOP/ CHMSL FUSE 8 STOPLAMP SWITCH (ABOVE BRAKE PEDAL) THROTTLE ACTUATOR CONTROL (TAC) MODULE (AT LEFT REAR OF ENGINE COMPARTMENT) TURN SIGNAL/ MULTIFUNCTION SWITCH UART SERIAL DATA UART SERIAL DATA UART SERIAL DATA UART SERIAL DATA SERIAL DATA 14 58 UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON RIGHT SIDE OF TRANSMISSION) VSS HIGH WHT WIRE YEL WIRE
