Chevrolet Chevy Express G3500 (1996-2012) ppl 10 3 13 cruise signal speed signal ignition auto cruise Wiring diagram
This page shows the only wiring diagram for the component.ppl 10 3 13 cruise signal speed signal ignition auto cruise, which is found in the car Chevrolet Chevy Express G3500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl 10 3 13 cruise signal speed signal ignition auto cruise (1 of 1)
BLK/WHT WIRE
BRAKE FUSE 18
BRN WIRE
CRUISE CONTROL MODULE (FRONT OF ENGINE COMPT NEAR LEFT FENDER)
CRUISE CONTROL SWITCH
CRUISE FUSE 6
DK BLU WIRE
DK GRN/WHT WIRE
ELECTRONIC BRAKE CONTROL MODULE (ON LEFT FRAME RAIL NEAR CENTER OF VEHICLE)
EXTERIOR LIGHT SYSTEM
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK (LEFT LOWER KICK PANEL)
LT BLU/BLK WIRE
LT GRN/BLK WIRE
OFF
ON PNK WIRE
ORG/ WIRE
PPL
PPL 10 3 13 CRUISE SIGNAL SPEED SIGNAL IGNITION AUTO CRUISE
PPL/WHT WIRE
R/A
RADIO ASSEMBLY
S/C
SPEED INPUT
STOP FUSE 1
TCC/STOPLAMP SWITCH (ON BRAKE PEDAL SUPPORT)
VCM SIGNAL SPEED SENSOR INPUT
VEHICLE CONTROL MODULE (VCM) (LEFT SIDE OF ENGINE COMPT)
VEHICLE SPEED SENSOR (VSS) (LEFT SIDE OF TRANSMISSION)
VSS HIGH
VSS LOW
WHT WIRE
Go to component -> 7.4l (vin j), cruise control circuit -> PPL 10 3 13 CRUISE SIGNAL SPEED SIGNAL IGNITION AUTO CRUISE
