Chevrolet Chevy Express G3500 (1996-2012) pnk cruise control, sound systems Wiring diagram
This page shows the only wiring diagram for the component.pnk cruise control, sound systems, which is found in the car Chevrolet Chevy Express G3500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk cruise control, sound systems (1 of 1)
8 VOLT REF
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION FLUID PRESSURE (TFP) MANUAL VALVE POSITION SWITCH
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS)
AUTOMATIC TRANSMISSION MANUAL SHIFT SWITCH
BLK WIRE
BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
FROM AUTOMATIC TRANSMISSION (DIAGRAM 1 OF 2)
GMLAN GMLAN SERIAL SERIAL DATA DATA BUS - BUS +
GMLAN SERIAL DATA BUS +
GRN WIRE
GROUND
GRY WIRE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (AT TOP OF STEERING COLUMN)
INPUT SHAFT SPEED (ISS) SENSOR
INPUT SPEED SENSOR (ISS) SIGNAL
LT BLU WIRE
OUTPUT SHAFT SPEED (OSS) SENSOR
OUTPUT SPEED SENSOR (OSS) SIGNAL
PNK CRUISE CONTROL, SOUND SYSTEMS WIRE
PNK WIRE
PPL
RED WIRE
REF
TAN WIRE
TAN/BLK WIRE
TAP UP/ TAP DOWN SW SIG
TFP SWITCH 1
TFP SWITCH 3
TFP SWITCH 4
TFP SWITCH 5
TOW/ HAUL SW SIG
TRANSMISSION CONTROL MODULE (TCM) CONTROL SOLENOID VALVE ASSEMBLY
TRANSMISSION RANGE SWITCH SIG A
TRANSMISSION RANGE SWITCH SIG B
TRANSMISSION RANGE SWITCH SIG C
TRANSMISSION RANGE SWITCH SIG P
WHT WIRE
YEL WIRE
Go to component -> Transmission circuit (2 of 2) -> PNK CRUISE CONTROL, SOUND SYSTEMS WIRE
