Chevrolet Chevy Express G3500 (1996-2012) coolant heater temperature sensor Wiring diagrams
This page contains all the electrical diagrams for the component. coolant heater temperature sensor, in which he is found in the car Chevrolet Chevy Express G3500 (1996-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram coolant heater temperature sensor (1 of 2)
A/C LOW PRESSURE SWITCH (ON SIDE OF ACCUMULATOR)
AUXILIARY AIR TEMPERATURE ACTUATOR
AUXILIARY BLOWER MOTOR (ON AUXILIARY HVAC)
AUXILIARY BLOWER MOTOR MEDIUM SPEED RELAY
AUXILIARY BLOWER MOTOR RESISTOR (ON AUXILIARY HEATER MOTOR)
AUXILIARY HVAC MODULE)
AUXILIARY MODE ACTUATOR
BATT GND
BLK WIRE
BLK/WHT WIRE
BREAKOUT)
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLANT HEATER BLOWER MOTOR
COOLANT HEATER COMBUSTION SENSOR
COOLANT HEATER CONTROL MODULE
COOLANT HEATER GLOW PLUG
COOLANT HEATER OVERHEAT TEMPERATURE SENSOR COOLANT HEATER AIR TEMPERATURE SENSOR
COOLANT HEATER TEMPERATURE SENSOR
DK BLU WIRE
DK BLU/LT GRN WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
ENGINE COOLANT LEVEL SWITCH
ENGINE COOLANT TEMPERATURE GAUGE
FOH MDL FUSE 35
FROM AUXILIARY BLOWER MOTOR BREAKOUT)
FROM AUXILIARY BLOWER MOTOR CONNECTOR BREAKOUT)
FUEL PUMP
GND SERIAL - SERIAL + SERIAL - SERIAL +
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOGIC COOLANT LEVEL SW SIG
LOW REF
LOW SPD GMLAN SERIAL DATA
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PROVISIONAL
RED/WHT WIRE
SERIAL DATA
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
VOLT
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit, cargo van (2 of 3) -> COOLANT HEATER TEMPERATURE SENSOR
