Chevrolet Chevy Express G3500 (1996-2012) 13 10 speed sig output vss output Wiring diagram
This page shows the only wiring diagram for the component.13 10 speed sig output vss output, which is found in the car Chevrolet Chevy Express G3500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 13 10 speed sig output vss output (1 of 1)
13 10 SPEED SIG OUTPUT VSS OUTPUT
BRAKE FUSE 18
BRN WIRE
CRUISE CONTROL ON/OFF SWITCH
CRUISE FUSE 6
CRUISE ON INPUT
DK BLU WIRE
ELECTRONIC BRAKE CONTROL MODULE (ON LEFT FRAME RAIL NEAR CENTER OF VEHICLE)
EXTERIOR LIGHT SYSTEM
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK (LEFT LOWER KICK PANEL)
LT GRN/BLK WIRE
ON PNK OFF WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND CENTER OF DASH)
PPL
PPL STOPLAMP SWITCH INPUT
PPL/WHT WIRE
R/A
RESUME/ACCEL SIG
S/C
SET/COAST SIG
SPEED SIGNAL INPUT
STOP FUSE 1
STOPLAMP SWITCH INPUT
TCC/BRAKE SWITCH (TOP OF BRAKE PEDAL)
VEHICLE SPEED SENSOR (VSS) (LEFT SIDE OF TRANSMISSION)
VEHICLE SPEED SENSOR BUFFER (BELOW DASH, NEAR STEERING COLUMN)
VSS HIGH
VSS LOW
WHT WIRE
YEL/BLK WIRE
Go to component -> 6.5l (vin f), cruise control circuit -> 13 10 SPEED SIG OUTPUT VSS OUTPUT
