5.3l vin t, charging circuit for Chevrolet Chevy Express G2500 (1996-2012)

BATTERY BATTERY IND BLK WIRE CLASS 2 SERIAL DATA DK GRN WIRE FUSIBLE LINK 3 GENERATOR GENERATOR FIELD DUTY CYCLE SIG GENERATOR TURN ON SIG GRY WIRE HOT IN RUN, START UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENG COMPT) IGN E FUSE 22 INSTRUMENT PANEL CLUSTER LOGIC IGN VOLT ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (IN ENG COMPT, ON LEFT INNER FENDER) RED WIRE STARTING/CHARGING SYSTEM (STARTER MOTOR)
