5.0l (vin m), anti-lock brake circuits for Chevrolet Chevy Express G2500 (1996-2012)

ABS FUSE ABS IND. BATTERY SIGNAL GROUND BLK WIRE BLK/WHT WIRE BRAKE FUSE 18 BRAKE IND BRAKE PRESSURE DIFFERENTIAL SWITCH (ON LEFT FRAME RAIL, NEAR CENTER OF VEHICLE) BRN WIRE COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) DK GRN WIRE GAUGES FUSE 4 HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START I/P FUSE BLOCK (ON LEFT LOWER KICK PANEL) IGNITION ABS IND GROUND BRAKE SW INPUT INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (IN ENGINE COMPT, ON LEFT INNER FENDER) PPL PPL PPL 1807 680 PPL/WHT WIRE RED WIRE RIGHT FRONT WHEEL SPEED SENSOR SENSOR HIGH SENSOR HIGH SENSOR LOW SENSOR LOW 873 833 TAN WIRE TAN/WHT WIRE TCC/STOPLAMP SWITCH (BEHIND DASH, ON BRAKE PEDAL SUPPORT) UNDERHOOD FUSE/RELAY CENTER UNDERHOOD FUSE/RELAY CENTER (ON LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON SIDE OF TRANSMISSION) VSS VSS SIG VSS SIG DIAGNOSTIC SIG SERIAL DATA BRAKE IND INPUT EBCM GROUND WARNING SYSTEMS YEL WIRE YEL/BLK WIRE
