Chevrolet Chevy Express G2500 (1996-2012) windshield wiper switch low signal Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper switch low signal, which is found in the car Chevrolet Chevy Express G2500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper switch low signal (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH)
DK PPL
FRONT WINDSHIELD WIPER SWITCH HI SIGNAL
GRN WIRE
GRY WIRE
HORN/ WASHER PCB
HOT AT ALL TIMES
LO INT
LOW REFERENCE
LT BLU WIRE
LT GRN WIRE
MIST
OFF
ORG/ WIRE
PNK WIRE
TAN WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WINDSHIELD WASHER RELAY CONTROL
WINDSHIELD WASHER SWITCH SIGNAL
WINDSHIELD WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER SWITCH HI SIGNAL
WINDSHIELD WIPER SWITCH LOW SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 2
WPR FUSE 55
WPR PCB
WPR-HI PCB
WSW FUSE 14
YEL WIRE
Go to component -> Wiper/washer circuit -> WINDSHIELD WIPER SWITCH LOW SIGNAL
