Chevrolet Chevy Express G2500 (1996-2012) w/ rke dome lamp override switch Wiring diagram
This page shows the only wiring diagram for the component.w/ rke dome lamp override switch, which is found in the car Chevrolet Chevy Express G2500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ rke dome lamp override switch (1 of 1)
ASH TRAY LAMP
BATTERY IGNITION DR JAMB SW GROUND DOME LAMP
BLK WIRE
BRIGHT ADJUST
BRN WIRE
CENTER DOME, READING LAMP
CON- VENIENCE CENTER
CTSY FUSE 3
DK GRN WIRE
DOME LAMP
DOME SWITCH
DOOR LOCK CONTROL MODULE (ON LEFT KICK PANEL)
DRIVER DOOR LOCK SWITCH DRIVER WINDOW SWITCH
FRONT DOME, READING LAMP
FRONT PASSENGER WINDOW SWITCH FRONT PASENGER DOOR LOCK SWITCH
GAUGES FUSE 4
GRY WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN, START
I/P COMPART- MENT LAMP
I/P FUSE BLOCK
IGNITION DR JAMB SW BATTERY GROUND
INTERIOR LAMP CONTROL MODULE (ON RIGHT LOWER KICK PANEL)
JAMB SWITCH W/ RKE
LAMP
LEFT FRONT DOOR JAMB SWITCH
LEFT FRONT STEPWELL LAMP RIGHT SIDE STEPWELL LAMP
LEFT VANITY MIRROR LAMP
NCA WIRE
ORG/ WIRE
PARADE MODE SWITCH
PARK LPS FUSE 9
PARK SWITCH
PNK 157 540 150 156 WIRE
PNK W/ RKE WIRE
PNK W/O RKE WIRE
PNK WIRE
PPL
PWR ACCY FUSE A
READING LAMPS
REAR DOME/ READING LAMP
REAR DOOR)
RIGHT FRONT DOOR JAMB SWITCH
RIGHT FRONT STEPWELL LAMP
RIGHT VANITY MIRROR LAMP
SIDE DOOR JAMB SWITCH
TO I/P FUSE BLOCK (DIAGRAM 2 OF 2)
W/ POWER DOOR LOCKS W/O POWER DOOR LOCKS
W/ RKE
W/ RKE DOME LAMP OVERRIDE SWITCH
W/ RKE W/O RKE
W/O RKE
W/O RKE PPL
WHT WIRE
Go to component -> Interior light circuit (1 of 2) -> W/ RKE DOME LAMP OVERRIDE SWITCH
