Chevrolet Chevy Express G2500 (1996-2012) theft deterrent module Wiring diagrams
This page contains all the electrical diagrams for the component. theft deterrent module, in which he is found in the car Chevrolet Chevy Express G2500 (1996-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram theft deterrent module (1 of 2)
AIR TEMPERATURE ACTUATOR
AMBIENT LIGHT SENSOR
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID
BCK/UP LAMP PCB
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BODY FUSE BLOCK (UNDER LEFT FRONT SEAT)
CARGO DR UNLOCK PCB
CENTER CONSOLE 2 ACCESSORY POWER OUTLET
CONNECTOR
DATA LINK CONNECTOR (DLC)
DRIVER INFORMATION CENTER (DIC) SWITCH
DRV UNLCK PCB
ELECTRONIC COMPASS MODULE
FTR REAR DR LOCK PCB
FTR REAR PASS DR UNLCK PCB
HEADLAMP, PANEL DIMMER SWITCH
HEAVY DUTY
HORN SWITCH
HVAC CONTROL ASSEMBLY
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) SENSOR
INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH
INFLATABLE RESTRAINT I/P MODULE INDICATOR
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INFLATABLE RESTRAINT VEHICLE ROLLOVER SENSOR
INSTRUMENT PANEL CLUSTER (IPC)
LEFT STEERING WHEEL CONTROL SWITCH
LIGHT DUTY
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT STEERING WHEEL CONTROL SWITCH
RUN WIRE
RV UPFITTER
STEERING WHEEL SPEED/ POSITION SENSOR
THEFT DETERRENT MODULE
TOW/ HAUL SWITCH
TOWARDS INSTRUMENT CLUSTER PANEL)
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ AUTOMATIC ELECTRONIC CRUISE CONTROL
W/ ELECTRIC SIDE DOOR LOCK CONTROL
W/ REAR WINDOW DEFOGGER, POWER MIRRORS
W/ REDUNDANT RADIO STEERING WHEEL CONTROL
W/ REMOTE KEYLESS ENTRY, LOW TIRE PRESSURE INDICATOR
W/O MANUAL SUPPRESSION SWITCH, RV UPFITTER
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (2 of 4) -> THEFT DETERRENT MODULE
Wiring diagram theft deterrent module (2 of 2)
AIR TEMPERATURE ACTUATOR
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID
BCK/UP LAMP PCB
BLK WIRE
BLK/ WHT WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BODY FUSE BLOCK (UNDER LEFT FRONT SEAT)
CARGO DR UNLCK PCB
CENTER CONSOLE 2 ACCESSORY POWER OUTLET
CONNECTOR
DATA LINK CONNECTOR (DLC)
DRIVER INFORMATION CENTER (DIC) SWITCH
DRVR DR UNLCK PCB
ELECTRONIC COMPASS MODULE
FTR REAR DR LCK PCB
FTR REAR PASS DR UNLCK PCB
HEADLAMP, PANEL DIMMER SWITCH
HEAVY DUTY
HORN SWITCH
HVAC CONTROL ASSEMBLY
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) SENSOR
INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH
INFLATABLE RESTRAINT I/P MODULE INDICATOR
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INFLATABLE RESTRAINT VEHICLE ROLLOVER SENSOR
INSTRUMENT PANEL CLUSTER (IPC)
LEFT STEERING WHEEL CONTROL SWITCH
LIGHT DUTY
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT STEERING WHEEL CONTROL SWITCH
RUN WIRE
RV UPFITTER
STEERING WHEEL SPEED/ POSITION SENSOR
THEFT DETERRENT MODULE
TOW/ HAUL SWITCH
TOWARDS INSTRUMENT CLUSTER PANEL)
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ AUTOMATIC ELECTRONIC CRUISE CONTROL
W/ ELECTRIC SIDE DOOR LOCK CONTROL
W/ REAR WINDOW DEFOGGER, POWER MIRRORS
W/ REDUNDANT RADIO STEERING WHEEL CONTROL
W/ REMOTE KEYLESS ENTRY, LOW TIRE PRESSURE INDICATOR
W/ VECHICLE COMMUNICATION SYSTEM
W/O MANUAL SUPPRESSION SWITCH, RV UPFITTER
W/O VECHICLE COMMUNICATION SYSTEM
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (3 of 5) -> THEFT DETERRENT MODULE
