Chevrolet Chevy Express G2500 (1996-2012) left up dn Wiring diagram
This page shows the only wiring diagram for the component.left up dn, which is found in the car Chevrolet Chevy Express G2500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left up dn (1 of 1)
BLK WIRE
BRN WIRE
CONVENIENCE CENTER (LEFT SIDE OF DASH)
DK BLU WIRE
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
FRONT PASSENGER WINDOW MOTOR
FRONT PASSENGER WINDOW SWITCH
HOT IN ACCY, RUN
I/P FUSE BLOCK (ON LOWER LEFT KICK PANEL)
LEFT UP DN
LT BLU WIRE
POWER WDO FUSE B
RIGHT DN
TAN WIRE
UP DN
YEL WIRE
Go to component -> Power window circuit -> LEFT UP DN
