Chevrolet Chevy Express G2500 (1996-2012) fuel tem sig brake apply sen sig low ref Wiring diagram
This page shows the only wiring diagram for the component.fuel tem sig brake apply sen sig low ref, which is found in the car Chevrolet Chevy Express G2500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel tem sig brake apply sen sig low ref (1 of 1)
2500 2501 COMPUTER DATA LINES SYSTEM
28 27 43 44 66 46 HI SPD SER DATA (+) HI SPD SER DATA (-)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION (EXCEPT 4.3L, 5.3L)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH)
BRAKE BRAKE POS POS LOW SEN (-) (+) (-) (+) REF SIG
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRK B+
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID
FUEL TEM SIG BRAKE APPLY SEN SIG LOW REF
GM LAN HI SPD
GRY WIRE
HI SPD SER DATA +
INTERNAL MODE SWITCH (IMS)
MODULE (TCM)
PARK/NEUTRAL POSITION (PNP) SWITCH
RED WIRE
SOL CTRL
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL
TRANSMISSION CONTROL MODULE (TCM) (6.6L:LEFT FRONT CORNER OF ENGINE COMPT)
VALVE ASSEMBLY
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> FUEL TEM SIG BRAKE APPLY SEN SIG LOW REF
