Chevrolet Chevy Express G2500 (1996-2012) drv dr unlck fuse 36 Wiring diagrams

1 2 3 4 BATTERY B+ SERIAL DATA BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH) CARGO DR UNLCK FUSE 33 CARGO DR UNLCK PCB RELAY CHIME MODULE (BEHIND LEFT CENTER OF DASH) COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DRV DR UNLCK FUSE 36 DRVR DR UNLCK PCB RELAY FRT DR LCK FUSE 31 FRT PASS DR UNLCK FUSE 34 FRT REAR PASS DR UNLCK PCB FTR REAR DR LCK PCB GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT AT ALL TIMES BODY FUSE BLOCK (UNDER LEFT FRONT SEAT) LEFT REAR SIDE DOOR JAM SWITCH (W/ HINGED DOOR) (AT LEFT "B" PILLAR) LIFTGATE AJAR SW SIG LO SPD GMLAN SERIAL DATA LO SPD SERIAL DATA LT BLU WIRE LT GRN WIRE ORG/BLK WIRE PNK/BLK WIRE RADIO REAR DR LCK FUSE 32 REAR OPEN SW REAR PASS DR UNLCK FUSE 35 RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (BEHIND CENTER OF DASH) RFA/TPM FUSE 21 RIGHT REAR SIDE DOOR JAM SWITCH (W/ CARGO PASSENGER) (AT RIGHT "B" PILLAR) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE W/ COMMERCIAL TRADESMAN W/ HINGED DOOR W/O COMMERCIAL TRADESMAN YEL WIRE YEL/BLK WIRE

1 2 3 4 BATTERY B+ SERIAL DATA BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH) CARGO DR UNLCK FUSE 33 CARGO DR UNLCK PCB RELAY CHIME MODULE (BEHIND LEFT CENTER OF DASH) COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DRV DR UNLCK FUSE 36 DRVR DR UNLCK PCB RELAY FRT DR LCK FUSE 31 FRT PASS DR UNLCK FUSE 34 FRT REAR PASS DR UNLCK PCB FTR REAR DR LCK PCB GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT AT ALL TIMES BODY FUSE BLOCK (UNDER LEFT FRONT SEAT) LEFT REAR SIDE DOOR JAM SWITCH (W/ HINGED DOOR) (AT LEFT "B" PILLAR) LIFTGATE AJAR SW SIG LO SPD GMLAN SERIAL DATA LO SPD SERIAL DATA LT BLU WIRE LT GRN WIRE ORG/BLK WIRE PNK/BLK WIRE RADIO REAR DR LCK FUSE 32 REAR OPEN SW REAR PASS DR UNLCK FUSE 35 RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (BEHIND CENTER OF DASH) RFA/TPM FUSE 21 RIGHT REAR SIDE DOOR JAM SWITCH (W/ CARGO PASSENGER) (AT RIGHT "B" PILLAR) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE W/ COMMERCIAL TRADESMAN W/ HINGED DOOR W/O COMMERCIAL TRADESMAN YEL WIRE YEL/BLK WIRE
