Power window circuit for Chevrolet Chevy Express G1500 (1996-2012)
Power window circuit
BLK WIRE
BRN WIRE
CONVENIENCE CENTER (LEFT SIDE OF DASH)
DK BLU WIRE
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
FRONT PASSENGER WINDOW MOTOR
FRONT PASSENGER WINDOW SWITCH
HOT IN ACCY, RUN
I/P FUSE BLOCK (ON LOWER LEFT KICK PANEL)
LEFT UP DN
LT BLU WIRE
POWER WDO FUSE B
RIGHT DN
TAN WIRE
UP DN
YEL WIRE
