Chevrolet Chevy Express G1500 (1996-2012) vcm signal speed sensor input Wiring diagrams
This page contains all the electrical diagrams for the component. vcm signal speed sensor input, in which he is found in the car Chevrolet Chevy Express G1500 (1996-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram vcm signal speed sensor input (1 of 3)
ANTI-LOCK BRAKES SYSTEM
AUTO CRUISE
BLK/WHT WIRE
BRAKE FUSE 18
BRN WIRE
CRUISE CONTROL MODULE (FRONT OF ENGINE COMPT NEAR LEFT FENDER)
CRUISE CONTROL ON/OFF SWITCH
CRUISE FUSE 6
DK BLU WIRE
DK GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN
I/P FUSE BLOCK (LEFT LOWER KICK PANEL)
INSTRUMENT CLUSTER SYSTEM
LT BLU/BLK WIRE
LT GRN/BLK WIRE
OFF
ON PNK WIRE
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT)
PPL
PPL/WHT WIRE
R/A
S/C
SPEED SIGNAL
STOP FUSE 1
TAN/WHT WIRE
TCC/BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
VCM SIGNAL SPEED SENSOR INPUT
VEHICLE SPEED SENSOR (VSS) (ON SIDE OF TRANSMISSION)
VSS HIGH
VSS LOW
WHT WIRE
Go to component -> 4.3l (vin w), cruise control circuit -> VCM SIGNAL SPEED SENSOR INPUT
