Chevrolet Chevy Express G1500 (1996-2012) vanity mirror lamp connector breakout) Wiring diagram
This page shows the only wiring diagram for the component.vanity mirror lamp connector breakout), which is found in the car Chevrolet Chevy Express G1500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vanity mirror lamp connector breakout) (1 of 1)
12 CM FROM LEFT FRONT DOME FLUORESCENT WORK LAMP CONNECTOR)
AUXILIARY 1 FUSE 32
BLK WIRE
BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH)
BODY FUSE BLOCK (UNDER LEFT FRONT SEAT)
CARGO DOOR LATCH ASSEMBLY
CTSY
CTSY LP RELAY 26
CTSY LP/ SEO FUSE 3
CTSY LPS SUPPLY BATTERY
DK BLU WIRE
DK BLU/WHT WIRE
DOME
DOME DEFEAT
DOME FLOUR- ESCENT FUSE 2
DOME FLUORESCENT WORK LAMP 1
DOME FLUORESCENT WORK LAMP 2
DOME FLUORESCENT WORK LAMP RELAY (AT LEFT "B" PILLAR)
DOME HNDL
DOOR OPEN SW SIG REAR DOOR AJAR CTSY LAMPS ON SIG REAR DOOR SW SIG
DRIVER DOOR LATCH ASSEMBLY
FL DOME LP SIG FL DOME RLY CTRL
GRY/BLK WIRE
HEADLAMP AND PANEL DIMMER SWITCH
HNDL
HOT AT ALL TIMES
LEFT FRONT DOME FLUORESCENT WORK LAMP
LEFT REAR DOME FLUORESCENT WORK LAMP
LEFT REAR DOOR JAMB SWITCH
LEFT VANITY MIRROR LAMP
LT GRN WIRE
NOT USED
ORG/ WIRE
PASSENGER DOOR LATCH ASSEMBLY
POWER
PPL
PPL DEFEAT SW SIG
PROVISIONAL
REAR FUSE BLOCK (ON LEFT "B" PILLAR)
RED WIRE
RED/WHT WIRE
RIGHT DOME FLUORESCENT WORK LAMP
RIGHT REAR DOOR JAMB SWITCH
RIGHT VANITY MIRROR LAMP
TAN WIRE
TBC 2 FUSE 18
UNDERHOOD LAMP
VANITY MIRROR LAMP CONNECTOR BREAKOUT)
WHT WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit, with upfitter package -> VANITY MIRROR LAMP CONNECTOR BREAKOUT)
