Chevrolet Chevy Express G1500 (1996-2012) reductant sensor module Wiring diagram
This page shows the only wiring diagram for the component.reductant sensor module, which is found in the car Chevrolet Chevy Express G1500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reductant sensor module (1 of 1)
4.3L
4.3L/5.3L
4.8L 6.0L
5.3L W/ HD TRUCK TRAILER W/O BACKUP ALARM
6.6L 6.6L 6.6L
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BREAKOUT)
CNG CONTROL MODULE
CONNECTOR BREAKOUT)
CONTROL SOLENOID VALVE ASSEMBLY
COOLANT FUEL HEATER HEATER
COOLANT HEATER FUEL PUMP
ENGINE CONTROL MODULE (ECM)
EXCEPT 5.3L W/ HD TRUCK TRAILER 4.8L, 6.OL, 4.3L W/O HD TRUCK TRAILER
EXCEPT 5.3L W/ HD TRUCK TRAILER, BACKUP ALARM
EXHAUST GAS RECIRCULATION (EGR) VALVE SHIELD
FUEL FILTER PRESSURE SWITCH
FUEL PRESSURE REGULATOR 1 SHIELD
FUEL PRESSURE REGULATOR 2 SHIELD
FUEL PUMP, SENDER ASSEMBLY
GLOW PLUG CONTROL MODULE (GPCM)
INTAKE (BLUNT AIR CUT) VALVE SHIELD SHIELD
LPG CUT OFF FUEL SOLENOID PUMP VALVE
NCA WIRE
REDUCTANT PUMP
REDUCTANT REDUCTANT LINE HEATER TANK HEATER
REDUCTANT SENSOR MODULE
SECONDARY PRIMARY LPG PUMP LPG PUMP ASSEMBLY ASSEMBLY
TRAILER CONNECTOR
W/ 3 TANK COMPLETE VEHICLE KIT, LPG
W/ 4 TANK COMPLETE VEHICLE KIT
W/ CARGO 6.6L, EXCEPT 5.3L W/ HD TRUCK TRAILER, BACKUP ALARM
W/ DEDICATED CNG
W/ FUEL FIRED 6.6L AUXILIARY HEATER
W/O DEDICATED CNG
WHT WIRE
WHT/ BLK WIRE
Go to component -> Ground distribution circuit (2 of 5) -> REDUCTANT SENSOR MODULE
