Chevrolet Chevy Express G1500 (1996-2012) in-line resistor Wiring diagram
This page shows the only wiring diagram for the component.in-line resistor, which is found in the car Chevrolet Chevy Express G1500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram in-line resistor (1 of 1)
6 OHMS
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE PEDAL)
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
CONVEN- IENCE CENTER (UNDER LEFT SIDE OF I/P) INTERIOR LIGHTS SYSTEM
CONVENIENCE CENTER (UNDER LEFT SIDE OF I/P)
CRUISE CONTROL SYSTEM
DK BLU WIRE
DK GRN WIRE
DK LT
DK RIGHT FRONT PARK
HAZ SW TN SW
HAZARD
HAZARD FUSE 5
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK
IN-LINE RESISTOR
INSTRU- MENT CLUSTER RIGHT TURN IND.
LEFT
LEFT REAR PARK
LEFT SIDE MARKER LAMP
LEFT TURN IND
LICENSE LAMP
LT BLU WIRE
LT GRN WIRE
LT LEFT FRONT PARK
NORMAL
OFF HEAD PARK
ORG/ WIRE
PARK LPS FUSE 9
PNK WIRE
PPL
RIGHT
RIGHT REAR PARK
RIGHT SIDE MARKER LAMP
STOP FUSE 1
STOP, TAIL LAMP
TCC/ STOP LAMP SWITCH (TOP OF
TURN B/U FUSE 16
TURN PWR HAZ PWR FLSHR OUT GND
TURN SIGNAL LAMP
TURN/ HAZARD SWITCH
TURN/HAZARD LAMP FLASHER (I/P RELAY CENTER: BELOW CENTER OF I/P)
W/ OPTIONAL TRAILER WIRING PACKAGE (RIGHT REAR OF INTERIOR)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, with sealed beam lamps -> IN-LINE RESISTOR
