Chevrolet Chevy Express G1500 (1996-2012) hdlp- lo beam relay Wiring diagram
This page shows the only wiring diagram for the component.hdlp- lo beam relay, which is found in the car Chevrolet Chevy Express G1500 (1996-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hdlp- lo beam relay (1 of 1)
+BC
BLK WIRE
BODY CONTROL MODULE (BEHIND LOWER RIGHT SIDE OF DASH)
CLASS 2 SERIAL DATA
COMPOSITE SEALED
COMPOSITE+
DIMMER SWITCH SIGNAL
DK GRN WIRE
FLASH TO PASS SIGNAL
FTP
FUSIBLE LINK 2
GRY WIRE
HDLP- HI BEAM RELAY
HDLP- LO BEAM RELAY
HEAD
HEADLAMP DIMMER SWITCH
HEADLAMP ON IND
HEADLAMP ON SIGNAL
HEADLAMP, PANEL DIMMER SWITCH
HIGH BEAM INDICATOR
HIGH BEAM RELAY CONTROL
HOT AT ALL TIMES
IGN CLASS 2
INSTRUMENT PANEL CLUSTER
LED DIMMING SIGNAL
LEFT HI BEAM FUSE 44
LEFT HIGH BEAM HEADLAMP LEFT HEADLAMP
LEFT LO BEAM FUSE 43
LEFT LOW BEAM HEADLAMP
LOGIC CLASS 2 SERIAL DATA
LOW BEAM RELAY CONTROL
LT GRN WIRE
OFF
PARK
PNK HEADLAMP ON IND CONTROL WIRE
PNK WIRE
PNK/WHT WIRE
PPL/WHT WIRE
RED WIRE
RIGHT HEADLAMP
RIGHT HI BEAM FUSE 45
RIGHT HIGH BEAM HEADLAMP
RIGHT LO BEAM FUSE 42
RIGHT LOW BEAM HEADLAMP
SEALED
SPLICE PACK
TAN WIRE
TAN/WHT WIRE
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Headlamp control circuit -> HDLP- LO BEAM RELAY
