Pulse wiper/washer circuit, late production for Chevrolet Cavalier III (1995-2005)
Pulse wiper/washer circuit, late production
24,000 OHMS
270,000 OHMS
BLK WIRE
DK GRN WIRE
GRY WIRE
HOT IN ACCY, RUN
I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LOW PULSE DELAY
MIST
OFF
OFF LOW PULSE
OFF PULSE
PPL
RED WIRE
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER PUMP (IN WASHER RESERVOIR)
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER FUSE
WIPER MOTOR ASSEMBLY (ON LEFT SIDE OF FIREWALL) MUX 2
WIPER MOTOR CONTROL
YEL WIRE
