Cooling fan circuit for Chevrolet Cavalier III (1995-2005)
Cooling fan circuit
BLK WIRE
COOLING FAN FUSE
COOLING FAN MOTOR
COOLING FAN RELAY
COOLING FAN RLY CTRL
DK GRN WIRE
ECT SENSOR SIGNAL
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON TOP RIGHT REAR OF ENGINE)
HOT AT ALL TIMES
LOW REF
LT BLU WIRE
POWERTRAIN CONTROL MODULE (PCM) (ON RIGHT REAR OF ENGINE COMPT)
RED WIRE
UNDERHOOD FUSE BLOCK (LEFT FRONT OF ENGINE COMPT)
WHT WIRE
YEL WIRE
