Chevrolet Cavalier III (1995-2005) left rear window switch Wiring diagram
This page shows the only wiring diagram for the component.left rear window switch, which is found in the car Chevrolet Cavalier III (1995-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear window switch (1 of 1)
1 2 3 UP DOWN EXPRESS DOWN
BLK WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DK LT PPL
DK PPL
EXPRESS DOWN MODULE
GRN WIRE
GRY WIRE
HOT IN RUN
I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
LEFT FRONT
LEFT FRONT WINDOW MOTOR
LEFT REAR
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LT BLU WIRE
LT GRN WIRE
MASTER WINDOW SWITCH
POWER WINDOW CIRCUIT BREAKER
PPL
REAR WINDOW LOCKOUT SWITCH
RIGHT FRONT
RIGHT FRONT WINDOW MOTOR
RIGHT REAR
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
SET OFF
SOLID STATE
SWITCH ILLUMINATION LAMP
TAN WIRE
Go to component -> Power windows circuit, 4 door -> LEFT REAR WINDOW SWITCH
