Chevrolet Cavalier III (1995-2005) inflatable restraint steering wheel module coil Wiring diagram

10,000 OHMS 15 16 PPL PPL 1807 1807 SERIAL DATA CLASS 2 SERIAL DATA CLASS 2 AIR BAG FUSE AIR BAG INDICATOR BLK WIRE BLK/WHT WIRE BODY COMPUTER MODULE (BCM) (BEHIND LOWER LEFT SIDE OF DASH) BRN WIRE CASE GROUND CLASS 2 (SDM) DATA LINK CONNECTOR (DLC) (PARTIAL) (BELOW LEFT SIDE OF DASH) PPL DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE (NEXT TO MASTER CYLINDER) GRY WIRE HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) IGN IGNITION INFLATABLE RESTRAINT I/P MODULE INFLATABLE RESTRAINT STEERING WHEEL MODULE INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE (ON DRIVER SEAT BACK) LOW CONTROL LOW CONTROL NCA WIRE POWERTRAIN CONTROL MODULE (PCM) (ON RIGHT REAR OF ENGINE COMPARTMENT) PPL PPL PPL 1807 1807 SERIAL DATA CLASS 2 SERIAL DATA CLASS 2 RIGHT FRONT INFLATABLE RESTRAINT SIDE IMPACT MODULE (ON PASSENGER SEAT BACK) SEAT BELT SWITCH (IN DRIVER SEAT BELT ASSEMBLY) SERIAL DATA CLASS 2 SHORTING BAR SIGNAL SIGNAL REFERENCE TAN WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
