Chevrolet Cavalier III (1995-2005) front passenger door jamb switch door lock relay Wiring diagram
This page shows the only wiring diagram for the component.front passenger door jamb switch door lock relay, which is found in the car Chevrolet Cavalier III (1995-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger door jamb switch door lock relay (1 of 1)
A/C COMP- RESSOR CLUTCH
A/C COMP- RESSOR CLUTCH DIODE
BLK WIRE
BLK/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP ASSEMBLY (CHMSL)
COOLING FAN
DOOR JAMB SWITCH- DRIVER
DOOR LOCK SWITCH- FRONT PASSENGER
ELECTRONIC BRAKE CONTROL MODULE
FRONT PASSENGER DOOR JAMB SWITCH DOOR LOCK RELAY
FUEL PUMP, SENDER ASSEMBLY
FUSE BLOCK- UNDERHOOD
HEATER BLOWER RELAY CRANK RELAY
LEFT BACK-UP LAMP
LEFT CENTER HIGH MOUNTED STOP LAMP ASSEMBLY
LEFT REAR APPLIQUE LAMP RIGHT REAR APPLIQUE LAMP
LEFT REAR DOOR JAMB SWITCH RIGHT REAR DOOR JAMB SWITCH
LEFT REAR MARKER LAMP
LICENSE LAMP
MASTER WINDOW SWITCH
NCA WIRE
ON FRAME RAIL)
PONTIAC
RADIO
REAR COMPARTMENT LID RELEASE ACTUATOR SEAT BELT SWITCH
REAR WINDOW DEFOGGER GRID
RIGHT BACK-UP LAMP
RIGHT CENTER HIGH MOUNTED STOP LAMP ASSEMBLY
RIGHT REAR MARKER LAMP
SEDAN
SEDAN, COUPE
TAIL/ STOP, TURN SIGNAL LAMP- RIGHT
TAIL/ STOP/ TURN LAMP LEFT
W/ KEYLESS REMOTE
W/ MANUAL A/C
W/ SPOILER
W/O KEYLESS REMOTE
W/O SPOILER
Go to component -> Ground distribution circuit (3 of 3) -> FRONT PASSENGER DOOR JAMB SWITCH DOOR LOCK RELAY
