Chevrolet Cavalier III (1995-2005) ajar switch Wiring diagram
This page shows the only wiring diagram for the component.ajar switch, which is found in the car Chevrolet Cavalier III (1995-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ajar switch (1 of 1)
AJAR SWITCH
BATTERY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BEHIND LOWER LEFT SIDE OF DASH)
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH)
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT LID RELEASE ACTUATOR (ON REAR DECK LID)
REAR COMPARTMENT LID RELEASE SWITCH
RFA BATT FUSE
TRUNK RELEASE CONTROL
TRUNK RELEASE INPUT
Go to component -> Trunk release circuit -> AJAR SWITCH
