Rear wiper/washer circuit for Chevrolet Captiva I facelift (2011-2013)
Rear wiper/washer circuit
BLK WIRE
BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
DK GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
I/P MULTI-FUNCTION SWITCH
INSTRUMENT CLUSTER SYSTEM
LIFTGATE AJAR SW SIG
LOGIC
MOISTURE SENSOR CIRCUIT
PNK/BLK WIRE
REAR WINDOW WIPER CONTROL MODULE
REAR WINDOW WIPER SW SIG
REAR WINDSHIELD WASHER FLUID PUMP
REAR WPR FUSE
RED WIRE
RED/WHT WIRE
SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
