Rear differential lock circuit for Chevrolet Captiva I facelift (2011-2013)
Rear differential lock circuit
AWD/VENT FUSE
BLK WIRE
COIL TEMP SENS SIG LOCK SOLENOID CTRL LOW REFERENCE DIAGNOSTIC ENABLE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
GMLAN DATA BUS- GMLAN DATA BUS+
GROUND
HOT AT ALL TIMES
I/P FUSE BLOCK
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LT BLU WIRE
ORG/ WIRE
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
REAR WHEEL DRIVE MODULE CLUTCH
RED/WHT WIRE
SERIAL DATA
SERIAL DATA B+
TAN WIRE
TAN/BLK WIRE
