Starting circuit for Chevrolet Captiva I facelift (2011-2013)

Starting circuit

Get access

3.0L AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) BATTERY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE) BUS - CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY ENGINE CONTROL MODULE (ECM) GRY WIRE IGN IGNITION SWITCH LOCK ORG/BLK WIRE PPL PPL/WHT WIRE RED WIRE RLY CTRL RUN WIRE SERIAL DATA STARTER MOTOR STRTR FUSE STRTR RELAY TAN WIRE TAN/BLK WIRE TRANS PARK NEUTRAL SIG TRANSMISSION CONTROL MODULE (TCM) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE
