Power top/sunroof circuit for Chevrolet Captiva I facelift (2011-2013)

Power top/sunroof circuit

Get access

BATTERY POS VOLT BLK WIRE BLU WIRE BRN WIRE GRN WIRE GRN/BLK WIRE GROUND HOT AT ALL TIMES HOT W/ ACC/RAP RELAY ENERGIZED I/P FUSE BLOCK IGN LOW REF ORG/ WIRE ORG/BLK WIRE PNK GROUND WIRE RED WIRE S/ROOF BATT FUSE SUNROOF CONTROL MODULE (REAR OF SUNROOF MODULE) SUNROOF FUSE SUNROOF MOTOR SUNROOF SW EXPRESS SIG SUNROOF SW OPEN SIG SUNROOF SW OPEN VENT SIG SUNROOF SWITCH WHT WIRE YEL WIRE
