3.0l vin 5, cooling fan circuit for Chevrolet Captiva I facelift (2011-2013)

3.0l vin 5, cooling fan circuit

Get access

BLK WIRE DK BLU WIRE DK GRN WIRE ENGINE CONTROL MODULE (ECM) (LEFT FRONT ENGINE COMPT) FAN 1 FUSE FAN 1 RELAY FAN 2 RELAY FAN 3 FUSE FAN 3 RELAY GRY WIRE HI SPD RLY CTRL HOT AT ALL TIMES LEFT ENGINE COOLING FAN LOW SPD RLY CTRL LT BLU WIRE RIGHT ENGINE COOLING FAN UNDERHOOD FUSE BLOCK
