Chevrolet Captiva I facelift (2011-2013) right rear left rear speaker tweeter speaker Wiring diagram

1 2 3 4 5 6 7 8 BATT POS VOL AMP FUSE AUDIO AMPLIFIER BLK WIRE BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM PNK WIRE CTRL SIG DATA SERIAL DELUXE 10 SPEAKER DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK IGN INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER SPEAKER LEFT REAR SPEAKER LH SUBWOOFER OUTPUT (+) RH SUBWOOFER OUTPUT (+) GND LH SUBWOOFER OUTPUT (-) RH SUBWOOFER OUTPUT (-) LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE ORG/ WIRE PNK TRANSMISSIONS SYSTEM (I/P HARNESS, UNDER CENTER CONSOLE) WIRE PNK WIRE PPL RED/WHT WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER SPEAKER RIGHT REAR CENTER I/P SPEAKER TWEETER SPEAKER RIGHT REAR LEFT REAR SPEAKER TWEETER SPEAKER RIGHT STEERING WHEEL CONTROL SWITCH TAN WIRE WHT WIRE YEL WIRE
