Rear wiper/washer circuit for Chevrolet Captiva I facelift 2 (2013-2016)
Rear wiper/washer circuit
ACC VOLT
BLK WIRE
BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
DK GRN WIRE
FRONT WIPER/ WASHER CIRCUIT
GROUND
GRY WIRE
HOT AT ALL TIMES
I/P MULTI-FUNCTION SWITCH
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LIFTGATE AJAR SW SIG
LOGIC
MOISTURE SENSOR CIRCUIT
PNK/BLK WIRE
REAR WINDOW WASHER PUMP (IN WASHER FLUID RESERVOIR)
REAR WINDOW WASHER PUMP CTRL
REAR WINDOW WIPER CONTROL MODULE
REAR WINDOW WIPER SW SIG
REAR WINDSHIELD WASHER FLUID PUMP
REAR WIPER MOTOR MODULE
REAR WPR FUSE
RED WIRE
RED/WHT WIRE
SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
