Moisture sensor circuit for Chevrolet Captiva I facelift 2 (2013-2016)
Moisture sensor circuit
18 14 OUTSIDE MOISTURE SIG 1 OUTSIDE MOISTURE SIG 1
ACCESSORY VOLTAGE
BAT POS VOLT
BCM FUSE
BLK WIRE
BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
GRN WIRE
GROUND MOISTURE SENSOR (IF EQUIPPED) (BEHIND REARVIEW MIRROR) LOGIC
HOT AT ALL TIMES
LT GRN WIRE
OUTSIDE ACCESS MOISTURE VOLT SENSOR SIGNAL
OUTSIDE MOISTURE SENSOR SIGNAL
RED/ WHT WIRE
RED/WHT WIRE
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WINDSHIELD OUTSIDE
