Power windows circuit for Chevrolet Captiva I facelift 2 (2013-2016)
Power windows circuit
BLK WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER WINDOW MOTOR (LEFT FRONT DOOR)
DRIVER WINDOW SWITCH
DRV P/WIN FUSE
HOT W/ ACC/RAP RELAY ENERGIZED
I/P FUSE BLOCK
LEFT FRONT
LEFT REAR
LEFT REAR WINDOW MOTOR (LEFT REAR DOOR)
LEFT REAR WINDOW SWITCH DN UP
LOGIC
LT BLU WIRE
LT GRN WIRE
PASS P/WIN FUSE
PASSENGER WINDOW MOTOR (RIGHT FRONT DOOR)
PASSENGER WINDOW SWITCH
PPL
PPL PPL
PPL/WHT WIRE
RIGHT FRONT
RIGHT REAR
RIGHT REAR WINDOW MOTOR (RIGHT REAR DOOR)
RIGHT REAR WINDOW SWITCH UP DN
TAN WIRE
WINDOW LOCKOUT SWITCH
YEL WIRE
