3.0l vin 5, cooling fan circuit for Chevrolet Captiva I facelift 2 (2013-2016)
3.0l vin 5, cooling fan circuit
BLK WIRE
DK BLU WIRE
DK GRN WIRE
ECM FUSE
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT ENGINE COMPT)
FAN 1 FUSE
FAN 1 RELAY
FAN 2 RELAY
FAN 3 FUSE
FAN 3 RELAY
GRY WIRE
HI SPD RLY CTRL
HOT AT ALL TIMES
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
LEFT COOLING FAN MOTOR
LEFT ENGINE COOLING FAN
LOW SPD RLY CTRL
LT BLU WIRE
RIGHT COOLING FAN MOTOR
RIGHT ENGINE COOLING FAN
UNDERHOOD FUSE BLOCK
