Chevrolet Captiva I facelift 2 (2013-2016) release rly ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. release rly ctrl, in which he is found in the car Chevrolet Captiva I facelift 2 (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram release rly ctrl (1 of 2)
BATT 1 FUSE
BLK WIRE
BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
GMLAN SERIAL DATA
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
IPC FUSE
L/GATE FUSE
LIFTGATE AJAR SIG
LIFTGATE AJAR SW SIG
LIFTGATE LATCH ASSEMBLY
LIFTGATE RELEASE LIFTGATE OPEN IND
LIFTGATE UNLATCH RELAY
LIFTGATE UNLATCH SW SIG
LIFTGATE UNLATCH SWITCH
LOGIC
LT BLU WIRE
PNK/BLK WIRE
REAR WIPER CONTROL MODULE
RED/WHT WIRE
RELEASE RLY CTRL
TRUNK RELEASE RELAY CTRL
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> Liftgate release circuit -> RELEASE RLY CTRL
Wiring diagram release rly ctrl (2 of 2)
BLK WIRE
BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
CLASS 2 (BCM)
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DOOR AJAR IND
GMLAN SERIAL DATA
HOT AT ALL TIMES
I/P FUSE BLOCK
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE
LIFTGATE AJAR SW SIG
LIFTGATE LATCH ASSEMBLY
LIFTGATE RELEASE SWITCH
LIFTGATE UNLATCH SW SIG
LOGIC
LT BLU WIRE
PNK/BLK WIRE
REAR CLOSURE FUSE
RED/WHT WIRE
RELEASE RLY CTRL
RLYS PCB RELAY
TRUNK RELEASE RELAY CTRL
WIPER/WASHER SYSTEM
Go to component -> Trunk, tailgate, fuel door circuit -> RELEASE RLY CTRL
