Chevrolet Captiva I facelift 2 (2013-2016) rear closure fuse Wiring diagram
This page shows the only wiring diagram for the component.rear closure fuse, which is found in the car Chevrolet Captiva I facelift 2 (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear closure fuse (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (FRONT OF CENTER FLOOR CONSOLE)
BRN WIRE
CLASS 2 (BCM)
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DOOR AJAR IND
GMLAN SERIAL DATA
HOT AT ALL TIMES
I/P FUSE BLOCK
INSTRUMENT PANEL CLUSTER (IPC)
IPC FUSE
LIFTGATE AJAR SW SIG
LIFTGATE LATCH ASSEMBLY
LIFTGATE RELEASE SWITCH
LIFTGATE UNLATCH SW SIG
LOGIC
LT BLU WIRE
PNK/BLK WIRE
REAR CLOSURE FUSE
RED/WHT WIRE
RELEASE RLY CTRL
RLYS PCB RELAY
TRUNK RELEASE RELAY CTRL
WIPER/WASHER SYSTEM
Go to component -> Trunk, tailgate, fuel door circuit -> REAR CLOSURE FUSE
