Chevrolet Captiva I facelift 2 (2013-2016) hot w/ engine controls ignition relay energized Wiring diagrams
This page contains all the electrical diagrams for the component. hot w/ engine controls ignition relay energized, in which he is found in the car Chevrolet Captiva I facelift 2 (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hot w/ engine controls ignition relay energized (1 of 4)
BLK WIRE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN MOTOR
COOLING FAN RESISTOR (RIGHT SIDE OF RADIATOR)
DK BLU WIRE
DK GRN WIRE
ECM FUSE
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
FAN 1 FUSE
FAN 3 FUSE
GRY WIRE
HI SPD RLY CTRL
HOT AT ALL TIMES
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
LOW SPD RLY CTRL
LT BLU WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> 2.4l vin k, cooling fan circuit -> HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
Wiring diagram hot w/ engine controls ignition relay energized (2 of 4)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
ECM FUSE
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT ENGINE COMPT)
FAN 1 FUSE
FAN 1 RELAY
FAN 2 RELAY
FAN 3 FUSE
FAN 3 RELAY
GRY WIRE
HI SPD RLY CTRL
HOT AT ALL TIMES
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
LEFT COOLING FAN MOTOR
LEFT ENGINE COOLING FAN
LOW SPD RLY CTRL
LT BLU WIRE
RIGHT COOLING FAN MOTOR
RIGHT ENGINE COOLING FAN
UNDERHOOD FUSE BLOCK
Go to component -> 3.0l vin 5, cooling fan circuit -> HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
Wiring diagram hot w/ engine controls ignition relay energized (3 of 4)
1 2 65 2150 PPL MTR SPLY VOLT LOW REF
2.4L
3.0L
6 21 22 PRESS SENS SIG
65 2150 PPL MTR SPLY VOLT LOW REF
8 24 ECT SENS SIG LOW REF
950 3040 GND BATT POS VOLT
A/C COMP RELAY (PCB)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY (PCB)
A/C FUSE
A/C REFRIGERANT PRESSURE SENSOR (IN A/C HIGH SIDE PRESSURE LINE)
AMBIENT AIR TEMPERATURE SENSOR (BEHIND FRONT GRILLE)
BLK WIRE
BLK/WHT WIRE
BLOCK (LEFT SIDE OF ENGINE COMPT)
BLOWER MOTOR (RIGHT SIDE OF HVAC)
BLOWER MOTOR CONTROL MODULE (BOTTOM OF HVAC ASSEMBLY)
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN RESISTOR (2.4L) (RIGHT SIDE OF RADIATOR)
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM FUSE
ENGINE CONTROL MODULE (ECM) (2.4L: LEFT REAR OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT SIDE OF CYLINDER HEAD)
ENGINE COOLING FAN RESISTOR (2.4L)
EXCEPT 2.4L
FAN 1 FUSE
FAN 1 RELAY
FAN 1 RELAY (3.0L) COOLING FAN LOW SPEED RELAY (2.4L)
FAN 2 RELAY (3.0L)
FAN 2 RELAY (EXCEPT
FAN 3 FUSE
FAN 3 RELAY
FAN 3 RELAY (3.0L) COOLING FAN HIGH SPEED RELAY (2.4L)
GND BATT POS VOLT
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
INSIDE AIR TEMPERATURE SENSOR
LEFT COOLING FAN MOTOR
LEFT ENGINE COOLING FAN (EXCEPT 2.4L) ENGINE COOLING FAN (2.4L)
LOW REF
LOWER AIR TEMPERATURE SENSOR (LEFT SIDE OF INSTRUMENT PANEL)
LT BLU WIRE
MTR SPD CTRL
OF ENGINE COMPT)
ORG/BLK WIRE
PPL
RED/WHT WIRE
RIGHT COOLING FAN MOTOR (3.0L)
RIGHT ENGINE COOLING FAN (EXCEPT 2.4L)
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE
UNDERHOOD FUSE BLOCK (LEFT SIDE
UPPER AIR TEMPERATURE SENSOR (BEHIND INSTRUMENT PANEL COMPARTMENT)
UPPER AIR TEMPERATURE SENSOR (BEHIND INSTRUMENT PANEL COMPT)
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
Wiring diagram hot w/ engine controls ignition relay energized (4 of 4)
