Chevrolet Captiva I facelift 2 (2013-2016) ambient light/ ambient sunload light sensor sensor Wiring diagram
This page shows the only wiring diagram for the component.ambient light/ ambient sunload light sensor sensor, which is found in the car Chevrolet Captiva I facelift 2 (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ambient light/ ambient sunload light sensor sensor (1 of 1)
2.4L
2.4L 3.0L
3.0L
3.0L 2.4L
A/C COMPRESSOR CLUTCH
A/T
ACC/ RAP RELAY
AMBIENT LIGHT SENSOR
AMBIENT LIGHT/ AMBIENT SUNLOAD LIGHT SENSOR SENSOR
AMBIENT LIGHT/ SUNLOAD SENSOR ENGINE COOLING FAN
AUTOMATIC TRANSMISSION SHIFT LEVER
AUTOMATIC TRANSMISSION SHIFT LEVER POSITION INDICATOR
AUXILIARY BRAKE BOOSTER IGNITION IGNITION PUMP COIL 4 COIL 6
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE
BRAKE BOOSTER PUMP IGNITION IGNITION MOTOR COIL 4 COIL 6
CENTER CONSOLE 1 ACCESSORY POWER OUTLET
CENTER CONSOLE 1 ACCESSORY POWER RECEPTABLE
CENTER CONSOLE 2 ACCESSORY POWER OUTLET
CENTER CONSOLE 2 ACCESSORY POWER RECEPTABLE
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR (DLC)
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER DOOR LATCH
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK RELAY
DRIVER HORN INFORMATION SWITCH CENTER (DIC) SWITCH
DRIVER INFORMATION CENTER (DIC) SWITCH
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER WINDOW SWITCH
FUEL DOOR LOCK RELAY
HEADLAMP SWITCH
HORN SWITCH
HVAC CONTROL MODULE
I/P FUSE BLOCK
I/P MULTI-FUNCTION SWITCH
IGNITION
IGNITION COIL 3
IGNITION IGNITION COIL 1 COIL 2
IGNITION LOCK CYLINDER CONTROL SOLENOID
INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSIDE AIR TEMPERATURE SENSOR
INSTRUMENT CLUSTER
INSTRUMENT PANEL CLUSTER (IPC)
LEFT COOLING FAN MOTOR
LEFT ENGINE COOLING FAN
LEFT TURN SIGNAL REPEATER LAMP
M/T
NCA WIRE
OUTSIDE DRIVER REARVIEW DOOR MIRROR LOCK SWITCH SWITCH
PANEL MODE ACTUATOR HARNESS BREAKOUT)
PARK BRAKE CONTROL SWITCH
PASSENGER DOOR LATCH
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER PASSENGER OUTSIDE WINDOW REARVIEW SWITCH MIRROR
PASSENGER WINDOW SWITCH
RELAY
RETAINED ACCESSORY POWER RELAY 1
RIGHT TURN SIGNAL REPEATER LAMP
RUN WIRE
RUN/ CRANK RELAY
SHIFT LEVER POSITION INDICATOR
STEERING COLUMN LOCK SOLENOID ACTUATOR
STEERING WHEEL AIR BAG COIL
TRANSMISSION SHIFT LEVER
TURN SIGNAL/ MULTIFUNCTION SWITCH
WHT/ BLK WIRE
Go to component -> Ground distribution circuit (2 of 3) -> AMBIENT LIGHT/ AMBIENT SUNLOAD LIGHT SENSOR SENSOR
