Rear washer/wiper circuit for Chevrolet Caprice IV (1990-1996)
Rear washer/wiper circuit
ACCESSORY SWITCH PANEL
BLK WIRE
FUSE BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
LIFTGATE WIPER LATCH SWITCH
OFF
OFF ON ON
ORG/ WIRE
PARK
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER/ WASHER AND MULTI- FUNCTION SWITCH
REAR WIPER WASHER MOTOR (ON WASHER RESERVOIR)
RR WIPER FUSE #8
RUN WIRE
SOLID STATE
TRK P/DOWN FUSE #36
WASH
WIPE
YEL WIRE
