Radio circuits for Chevrolet Caprice IV (1990-1996)
Radio circuits
ANTENNA
ANTENNA INPUT
BATTERY POWER
BLK/WHT WIRE
BRN WIRE
COAXIAL CABLE
DIM SIGNAL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
IGNITION POWER
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LT BLU WIRE
LT FRT SPKR
LT GRN WIRE
LT REAR SPKR
ON OUTPUT
ORG/ WIRE
PANEL LIGHT
POWER ANTENNA SYSTEM
RADIO
RADIO FUSE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
RT FRT SPKR
RT REAR SPKR
SPEED COMPENSATED VOLUME
TAN WIRE
YEL WIRE
