Power door locks circuit, without remote/keyless entry for Chevrolet Caprice IV (1990-1996)
Power door locks circuit, without remote/keyless entry
BLK WIRE
CTSY PWR LOCK FUSE 35
DOOR LOCK RELAY ASSEMBLY (BEHIND LEFT KICKPAD)
FUSE BLOCK
GRY WIRE
HOT AT ALL TIMES
LEFT DOOR LOCK SWITCH
LEFT REAR DOOR LOCK MOTOR
LOCK
LOCK RELAY
LT BLU WIRE
ORG/ WIRE
PWR ST CIRCUIT BREAKER 1
RIGHT DOOR LOCK SWITCH
RIGHT FRONT DOOR LOCK MOTOR
RIGHT REAR DOOR LOCK MOTOR
TAIL- GATE LOCK MOTOR LEFT FRONT DOOR LOCK MOTOR
TAN WIRE
UNLOCK
UNLOCK LOCK
UNLOCK RELAY
WAGON ONLY
WHT WIRE
