Car Wiring Diagrams for Headlight circuit, without drl, with twilight sentinel for Chevrolet Caprice IV (1990-1996)

AMBIENT LT SENSOR INPUT BLK WIRE BLK/WHT 1491 WIRE BLK/WHT WIRE BRN WIRE CONN 1 CONN 2 DK GRN/WHT WIRE EXT LPS FUSE EXTERIOR LTS FUS LINK A (UNDERHOOD ELECTRICAL CENTER) GROUND HEAD HEADLT AUTO CONTROL MODULE (ABOVE BASE OF STEERING COLUMN) HEADLT AUTO CTRL AMBIENT LT SENSOR HEADLT DIMMER HEADLT SW HI BEAM GROUND B+ HI-BEAM IND HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK CHIME FUSE INSTRUMENT CLUSTER INTERIOR, EXTERIOR LTS INTERNAL HEAD RELAY INTERNAL PARK RELAY LEFT DUAL BEAM HEADLT LT GRN LT GRN WIRE LT GRN WIRE LT GRN/BLK WIRE LTS ON INPUT LTS ON WARNING INPUT IGNITION DELAY ON/OFF OUTPUT #2 OUTPUT #1 MAX MIN PPL NOT USED OFF ORG/ WIRE PARK PNK PPL WIRE PNK WIRE RED WIRE RIGHT DUAL BEAM HEADLT TAN WIRE TWILIGHT SENTINEL SW WARNING ALARM (CONVENIENCE CENTER) YEL WIRE YEL/BLK WIRE
