Electronic level control for Chevrolet Caprice IV (1990-1996)
Electronic level control
4.5-7 MINUTES MAXIMUM. C-CLOSES WITH VEHICLE TOO LOW.
AUTOMATIC CONTROL LEVEL SENSOR
BLK WIRE
COM- PRESSOR MOTOR RELAY
COMPRESSOR MOTOR
COMPRESSOR SIGNAL
ELC FUSE
EXHAUST
EXHAUST SOLENOID
EXHAUST VALVE
FROM ACTU- ATOR ARM
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START HOT AT ALL TIMES LEVEL CONTROL FUSE INT/LPS FUSE
I/P FUSE BLOCK
LEVEL
NCA WIRE
NORMAL
ORG/ WIRE
PNK WIRE
POWER SOLID STATE
RESET+
TOO LOW TOO HIGH
UNDERHOOD ELECTRICAL CENTER
VENT
WHT WIRE
YEL WIRE
