Chevrolet Caprice IV (1990-1996) tail- gate lock motor left front door lock motor Wiring diagram
This page shows the only wiring diagram for the component.tail- gate lock motor left front door lock motor, which is found in the car Chevrolet Caprice IV (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail- gate lock motor left front door lock motor (1 of 1)
BLK WIRE
CTSY PWR LOCK FUSE 35
DOOR LOCK RELAY ASSEMBLY (BEHIND LEFT KICKPAD)
FUSE BLOCK
GRY WIRE
HOT AT ALL TIMES
LEFT DOOR LOCK SWITCH
LEFT REAR DOOR LOCK MOTOR
LOCK
LOCK RELAY
LT BLU WIRE
ORG/ WIRE
PWR ST CIRCUIT BREAKER 1
RIGHT DOOR LOCK SWITCH
RIGHT FRONT DOOR LOCK MOTOR
RIGHT REAR DOOR LOCK MOTOR
TAIL- GATE LOCK MOTOR LEFT FRONT DOOR LOCK MOTOR
TAN WIRE
UNLOCK
UNLOCK LOCK
UNLOCK RELAY
WAGON ONLY
WHT WIRE
Go to component -> Power door locks circuit, without remote/keyless entry -> TAIL- GATE LOCK MOTOR LEFT FRONT DOOR LOCK MOTOR
